SX-HB16 →16 kWh · 51.2 V · floor · IP65Core line · SX-HR high-voltage rack
LiFePO4 energy storage for distributors — from 1 kWh backup to 1.4 MWh racks.
Our core line for indoor C&I sites: 16 kWh modules carried in one by one, fire suppression in every module, built for Deye and Solis three-phase hybrid inverters.
- 48–241 kWh per cluster
- 3–15 modules
- up to 1.4 MWh
SX-HR-AHigh-voltage rack, forced-air cooling16.076 kWh per module · 51.2 V / 314 Ah
Home battery storage
Store the midday sun for the evening peak.
51.2 V wall, floor and rack batteries for single-phase hybrid inverters, and a stackable high-voltage line for three-phase homes.
- 2.5–20 kWh per LV unit
- 51.2 V and high-voltage
- IP65 floor units
SX-HB16Floor-standing home battery16 kWh · 51.2 V · IP65
Portable power & home backup
Keep the lights on when the grid goes down.
Power stations for homes, shops and field work, from 1 kWh to an expandable 19 kWh system. Mixed into the same container as your batteries.
- 1–5 kWh stations
- expand to 19 kWh
- 6000 W AC on SX-E50 Pro
SX-P20Portable power station2048 Wh · 2400 W AC
C&I PV-storage cabinets & container
Battery and hybrid inverter in one cabinet.
Outdoor PV-storage cabinets with the hybrid inverter built in: connect the solar array, the grid and the loads, and the site shaves its peaks and rides through outages. Storage-only cabinets and a 20 ft container for larger projects.
- hybrid inverter built in
- PV input up to 250 kW
- backup switch <10 ms
125 kW / 261 kWhPV-storage cabinet, hybrid inverter built inPV up to 250 kW · IP54 + IP66
Core line · SX-HR
High-voltage rack battery for indoor commercial storage.
Fills the gap between home battery stacks and outdoor cabinets. Start at 48 kWh, add modules as the site grows, and keep the system in an existing plant room.
Fire suppression in every module
Each module carries its own aerosol extinguisher, so the safety design follows the battery into the room.
Carried in, not craned in
Modules ship as separate units and connect by cable on site. No crane, no outdoor foundation.
Grows module by module
3 to 15 modules per cluster, up to 6 clusters in parallel for about 1.4 MWh.
On Deye and Solis battery lists
Approved pairing with the Deye SUN-50K-SG01HP3-EU-BM4 and Solis S6-EH3P10K2-H three-phase hybrid inverters; Hoymiles and Sofar HV models tested.
SX-HR-A · forced air
For higher daily cycling and warm plant rooms.
SX-HR-N · natural cooling
No fans: quiet, less dust, less service. European stock for this version.
| Modules | Energy | Nominal voltage | Typical site |
|---|---|---|---|
| 3 | 48.2 kWh | 153.6 V | Shop, cold room |
| 5 | 80.4 kWh | 256 V | Workshop, school |
| 7 | 112.5 kWh | 358.4 V | Small factory, hotel |
| 10 | 160.8 kWh | 512 V | Factory, clinic |
| 15 | 241.1 kWh | 768 V | Large building |
| 6 × 15 | 1.45 MWh | parallel clusters | Multi-cluster site |
16.076 kWh, 51.2 V / 314 Ah per module. Inverter pairing and the final cluster size are confirmed in the quotation; more than 6 clusters need a distribution cabinet.
Home battery storage
Home batteries for installers.
51.2 V low-voltage batteries for single-phase hybrid and off-grid inverters, and a stackable high-voltage line for three-phase homes.
SX-HB16 →16 kWh · 51.2 V · floor · IP65
SX-H-LV51-FS392 →20 kWh · 51.2 V · floor · IP65
SX-H-LV51-W →5.12 / 10.24 kWh · 51.2 V · wall
SX-H-HV →10.4–62.6 kWh · 102–614 V · stackInverter compatibility
On the inverter maker’s approved battery list
- Deye SUN-5K-SG04LP1-EU-SM2
- Deye SUN-20K-SG05LP3-EU-SM2
- Solis S6-EH1P6K-L-PLUS
- Luxpower SNA6000 WPV
Tested with
- Victron MultiPlus-II 48/6k5
- SMA Sunny Island SI 6.0H
- Growatt SPF 6000 ES PLUS
- Sungrow MG6RL
- Hoymiles HYS-6.0LV
- Megarevo
- Voltronic INFINI V4
- SRNE HSI 5500
- MUST PV1800
- +6 more
Pylon CAN 500 kbit/s or RS485 Modbus. Full compatibility list by model →
Also in the range: SX-H-LV51-RK and SX-H-LV48-RK rack modules; SX-H-LV51-ST stackable and SX-H-LV25 25.6 V batteries Africa · LatAm · SE Asia
Portable & home backup
Power stations and backup units.
From a 1 kWh backup box that switches over in under 20 ms to a 5 kWh station that expands to 19 kWh. Portable power station buying guides →
SX-U10 / SX-U20 →1 / 2 kWh · UPS <20 ms
SX-P10P →1 kWh class · portableSX-P20 →2048 Wh · 2400 W
SX-E50 Pro →5120 Wh → 19 kWh · 6000 WC&I cabinets & container
C&I storage with or without a hybrid inverter.
PV-storage cabinets come with the hybrid inverter mounted and wired; storage-only cabinets and the container connect to the site’s own PCS. All configured and quoted per project.
PV-storage cabinet 125 →125 kW / 261 kWh · PV up to 250 kW · backup <10 ms
PV-storage cabinet 50 →50 kW / 112 kWh · IP55 + IP65 · backup <10 ms
Liquid-cooled cabinet →125 kW / 261 kWh · IP54 · Modbus TCP
20 ft container →250 / 500 kW class · per projectMarkets
Where we supply.
SunoraX is a B2B supplier of LiFePO4 energy storage, founded in 2025 in Guangzhou, China. Products are built by our manufacturing partner and supplied to distributors, importers and installers in Europe, Africa, Latin America (excluding Brazil) and Southeast Asia.
Europe
Home batteries, HV racks, balcony storage. FOB China, or from European stock by volume.
Mixed containersBatteries, racks and stations in one shipment.
OEM / ODMLogo, colour, packaging and app branding.
DeliveryFOB China, or from European stock by volume.
DocumentsCE, UN38.3 and MSDS confirmed by model.
ReplyWritten quotation within one business day.
Questions
Questions from distributors.
What is a high-voltage rack battery used for?
Commercial sites with a three-phase hybrid inverter that need 48 to 241 kWh per cluster indoors: peak shaving, solar self-consumption and backup.
Can the rack be installed indoors?
Yes. It is designed for plant rooms, with fire suppression in each module. Local fire and installation rules are checked for each project.
Which inverter brands work with your batteries?
The 51.2 V batteries are matched with Deye, Growatt, Victron Energy, SMA, GoodWe, Sungrow, Solis, SRNE, Voltronic Power, Luxpower, SAJ, Sofar, MUST, Hoymiles and Megarevo over CAN or RS485. The SX-HR high-voltage rack works with Deye and Solis three-phase hybrid inverters. The exact model is confirmed for each order.
Can we mix product lines in one order?
Yes. Home batteries, racks, power stations and panels can ship in one container. MOQ is confirmed per model in the quotation.
